Space Terminals



The terminals are intended for the organization of high-speed communication channels at distances up to 50,000 km in outer space. The equipment can be used both in intersatellite communication channels and in the Space-Earth channels:


  • unified optical receiving-transmitting path and service information exchange protocol for any application scenarios;

  • function of measuring of the mutual angular coordinates and the inclined distance to the subscriber;

  • hemispherical viewing area with a double loop of the direction of communication stabilizing;

  • possibility of increasing the functions of equipment, considering the introduction of a quantum key distribution and video surveillance system (ERS);

  • the best transmission speed, dimensions, weight and power consumption.



 http://www.moctkom.ru/space-terminals/



SOT-90

SOT-150

Distance

5 000 km

50 000 km

Data rates

10 Gbps (upgrade to 100 Gbps)

1.25 Gbps

Weight

16 kg

50 kg

Autonomous Life

more than 7 years

more than 7 years

Dimensions

450x300x380 mm

600x400x480 mm

Power consumption

60 W

100 W
